BOMBTRACK 2022/2023 Beyond 2 - LAST BIKE AVAILABLE - Size S

€2,539.00 (Save €540.00)
€1,999.00
Tax included

27.5" XS - 27.5" S - 29" M - 29" L - 29" XL

LAST S AVAILABLE

Contact us: info@bikejamming.it



Secure payments and protected data



Secure & tracked delivery



Regulated and transparent withdrawal

This bike will take you further. Designed with the support of Bombtrack family of field testers, the Beyond 2 is the natural evolution of the Beyond 1. Tried and tested fast-rolling wheels, multiple mounting points, and a range of gears remain. A Supernova dynamo lighting system joins the bike’s features, so you never have to charge your batteries – ideal for excursions that go that little bit further. And at the front, a demi-porteur rack supports more cargo space that doesn’t compromise steering and handling.

Made to cross countries and continents on all types of surfaces, roads and tracks.

  • Adventure touring bike ready to go.
  • The Bombtrack answer for mixed-terrain touring.
  • Designed like the bike packers dream, its steel frame uses selected tubes, light and resistant.
  • The geometry of the bike ensures a comfortable and stable riding position even when fully loaded.
  • The flared handlebar and the rise of the pipe offer multiple support positions and help the shoulders and upper body to remain relaxed during your long rides.
  • The SRAM Apex 1X11 drivetrain is simple and fluid.

SINGLE CHAINRING: A well-established trend, the 36T single ring with 11-42 sprocket set guarantees graduality in the ratio scale and is designed for use on mixed surfaces, where a double chainring would end up hindering. The gear selection is immediate and the risk of chain falling in extreme conditions lower.

Less weight: The absence of the front derailleur is much appreciated by those who prefer a bikepacking or hybrid set-up, with particular attention to weight.

What is not there does not break: No front derailleur means less components subject to breakage and requiring maintenance.

More room: No front derailleur also translates into greater possibility of exploiting room on the frame, quite an advantage in the bikepacking mode.

Color 1 Glossy Metallic Root Beer
Color 2 -
Frame 4130 double butted crmo, TA, rack / fender mounts, internal light cable routing,
73 mm BSA BB shell
Fork 4130 crmo, double butted blades, TA, 1.1/2'' - 1.1/8'', fender / rack /
triple cage mounts, internal hub dynamo cable routing
Handlebar BOMBTRACK BEYOND travel bar, 31.8 mm, 30° flare
Grips BOMBTRACK COMMAND bar tape
Stem BOMBTRACK WANDER forged aluminium stem, +17°
Headset Sealed external aheadset, 1.1/2'' - 1.1/8''
Levers SRAM Apex double tap mechanic
Shifter SRAM Apex double tap 1 x 11
Brakes TRP SPYRE C mechanic disc brakes with 180 mm F / 160 mm R rotors
Crankset BOMBTRACK AMES forged aluminium crank, 24 mm spindle
BB BSA sealed BB, external cups
Pedals -
Chain KMC X11 chain, 1/2'' x 11/128'', 114L
Chainring Aluminium, narrow-wide, 36 T
Cassette SRAM PG-1130 11-speed, 11 - 42 T
Front derailleur -
Rear derailleur SRAM APEX 1, clutch, long cage
Front hub KT dynamo hub, 6-bolt disc
Rear hub BOMBTRACK ARC sealed hub, 11-speed, 6-bolt disc
Through axle 15 x 100 mm / 12 x 142 mm
Front rim WTB ST i23 double wall, TCS 2.0, 32h
Rear rim WTB ST i23 double wall, TCS 2.0, 32h
Saddle BOMBTRACK FUZZ
Seat post BOMBTRACK BEECH 27.2 mm x 400 mm
Seat clamp BOMBTRACK ORIGIN 29.8 mm
Front tire PANARACER GRAVELKING SK XS - S 48-584 /
M - XL 50-622, tubeless ready
Rear tire PANARACER GRAVELKING SK XS - S 48-584 /
M - XL 50-622, tubeless ready
Fender -
Rack BOMBTRACK DECK frontrack, aluminium
Kickstand -
Light SUPERNOVA E3 PURE 3 front, E3 TAIL LIGHT 2 rear
Weight 13.2 kg (size M)
Weight frameset 2540 g frame (size M, incl. TA, bolts, seatclamp, hanger) / 1500 g fork (300 mm steerer, incl. TA)
Maximum rider weight 140 kg incl. luggage
ASTM riding condition 2

Final product may vary in appearance, finish and minor details.

BUILD INFOS:

BB standard BSA - 73 mm shell width
Headset standard (S.H.I.S.) EC34 / 28.6 | EC44 / 40
Headset crown race angle 45°
Fork max tire clearance w/o fender XS - S 27.5'' x 2.1'' / M - XL 29'' x 2.1''
Frame max tire clearance w/o fender XS - S 27.5'' x 2.1'' / M - XL 29'' x 2.1''
Maximum chainring clearance 1x 36 T with 48 mm chainline
Maximum chainring clearance 2x 42 / 28 T with 49.5 mm chainline
Seat post diameter 27.2 mm
Seat clamp diameter 29.8 mm
Front derailleur clamp diameter 28.6 mm
Brake mount front PM
Brake mount rear FM
Maximum rotor clearance front 203 mm
Maximum rotor clearance rear 180 mm
Front through axle 15 mm x 100 mm, 1.5 thread pitch
Rear through axle 12 mm x 142 mm, 1.5 thread pitch
ISO testing standard MTB
Crankarm XS 165 mm / S - M 170 mm / L - XL 175 mm
Q Factor 179 mm
BCD crank 104 mm, 4 bolts
Chainline 50 mm
Chainring offset 0 mm
Spoke length front wheel XS - S 272mm / M - XL 292 mm
Spoke length rear wheel XS - S 274mm, 272 mm / M - XL 293 mm, 291 mm
Spoke count (front / rear) 32 / 32
ERD XS - S 570 mm / M - XL 606 mm
Front hub PCD 58 mm
Rear hub PCD 58 mm
Front hub flange distance / offset 46.8 mm center to center / 0 mm
Rear hub flange distance / offset 51 mm center to center / 8.8 mm
Stem length XS - S 60 mm / M - L 80 mm / XL 90 mm
Stem angle 17°
Headset spacers 1 x 10 mm, 2 x 5 mm, XL: 1 x 10 mm, 1 x 5 mm
Seat post offset 24 mm
Seat post length 415 mm
Derailleur hanger BT-DH-008
Frame small parts BT-CR-007
Hub end caps front BT-HC-011
Hub end caps rear BT-HC-017
Cassette body BT-CB-006
Crankarm bolt BT-CRP-001
Through axle front BT-TA-F-602
Through axle rear BT-TA-R-602

FRAME GEOMETRY:

Bike Size XS S M L XL
Wheel size 27.5'' 27.5'' 29'' 29'' 29''
Seat Tube Length 400 440 480 520 560
Horizontal TT length 494 522 558 590 623
Seat Angle 75.0° 74.5° 73.5° 73.0° 72.5°
Head Angle 70.0° 70.5° 71.0° 72.0° 72.0°
Headtube Length 100 130 150 190 220
BB Drop 55 55 70 70 70
Chainstay Length 425 425 455 455 455
Fork Offset 50 50 50 50 50
Trail 73 70 73 67 67
Wheelbase Length 1000 1021 1065 1082 1109
Standover 725 759 800 840 871
Reach 351 366 380 394 412
Stack 534 565 601 643 671
Front Center 581 602 620 636 663
Axle to Crown 416 416 416 416 416
Minimum rider height * 1500 1600 1700 1790 1880
Maximum rider height * 1610 1710 1810 1900 1990

¹ Bombtrack bike size recommendation generally represents a rough guideline for quickly narrowing down the sizes from which to choose based on the body height. Bike fitting is a complex topic and other measurements and factors have to be accounted for as well. Since no two human bodys are exactly the same it is not possible to give a 100% correct advice for everyone. Therefore BOMBTRACK cannot guarantee for the stated recommendations to be correct for every individual customer. The best way to work out the correct size is to consult us or a professional bike fitter and to determine the needed size.

HANDLEBAR GEOMETRY

Bike Size XS S M L XL
Handlebar type Dropbar Dropbar Dropbar Dropbar Dropbar
Width (drops) 420 420 440 440 460
Width (barends) 594 594 614 614 634
Reach 85 85 85 85 85
Flare 30° 30° 30° 30° 30°
Backsweep - - - - -
Drop 115 115 115 115 115
Upsweep - - - - -
Rise - - - - -
