BOMBTRACK Hook Frameset - Metallic Red

€1,198.00
Tax included

The Bombtrack Hook Frameset is a Columbus Cromor steel platform designed for fast gravel and sporty all-road riding, featuring a full carbon fork, T47 bottom bracket, and thru-axles. It is ideal for building a responsive and efficient bike for mixed surfaces, from hardpack gravel to rough tarmac, while still allowing setups for light bikepacking and performance-oriented commuting.

Considering a complete bike setup (cockpit, wheels and components)?

We can help you build a configuration that matches your real use.

→ See how the setup works



Secure payments and protected data



Secure & tracked delivery



Regulated and transparent withdrawal

Bombtrack Hook Frameset

The Bombtrack Hook Frameset in Metallic Red is a steel gravel / all-road frameset built from Columbus Cromor tubing with a full-carbon fork, designed for riders who want a fast, versatile bike for compact gravel, white roads and rough tarmac. Thru-axles, a T47 bottom bracket and multiple mounting points make it a solid platform for performance-oriented builds that still keep everyday practicality in mind.

What the frameset includes

  • Frame: Columbus Cromor double-butted steel, TA dropouts, rack/fender mounts, T47 86.5 mm bottom bracket shell.
  • Fork: full carbon with thru-axle, tapered 1.5"–1 1/8", triple cage mounts that can also be used as fender mounts, plus internal routing for a hub dynamo cable.
  • Headset: sealed external headset, 1.5"–1 1/8".
  • Thru-axles: front 12 × 100 mm, rear 12 × 142 mm (included).
  • Seatpost clamp: Bombtrack Prime 29.8 mm (included).

Intended use & possible builds

Fast gravel & all-road

Built around a lightweight steel frame and a full-carbon fork, the Hook is made for fast gravel riding: tyre clearance up to 700C × 42 mm allows efficient setups with enough grip and comfort for compact gravel and white roads.

Sport commuting & light bikepacking

With mounts for fenders, racks and triple cages on the fork, the frameset suits daily commuting or light bikepacking builds: 1x for simplicity, or 2x for riders who prefer tighter gear steps, with a broad choice of front chainrings within the frame’s stated limits.

Year-round mixed use

The combination of steel and carbon, together with flat-mount disc brakes, makes the Hook suitable for hard use in variable weather conditions. You can steer the build towards comfort or responsiveness by choosing tyres, wheels and drivetrain options within the standards supported by the frameset.

Compatibility & build info

Item Details
Bottom bracket standard T47, 86.5 mm shell width.
Headset standard (S.H.I.S.) EC34 / 28.6 (upper) | EC44 / 40 (lower).
Crown race angle 36°.
Fork steerer inner diameter 23.6 mm.
Max fork tyre clearance (without fenders) 650B × 52C / 700C × 45C.
Max frame tyre clearance (without fenders) XS–S: 650B × 42C / M–XL: 700C × 42C.
Max 1x chainring 40 teeth with 45 mm chainline.
Max 2x chainrings 48 / 32 teeth with 46.9 mm chainline.
Seatpost diameter 27.2 mm.
Seat clamp diameter 29.8 mm.
Front derailleur clamp diameter 28.6 mm.
Front derailleur compatibility yes.
Front brake mount flat mount 140 / 160 mm.
Rear brake mount flat mount 140 / 160 mm.
Max front rotor 160 mm.
Max rear rotor 160 mm.
Front thru-axle 12 × 100 mm, 1.5 thread pitch.
Rear thru-axle 12 × 142 mm, 1.5 thread pitch.
ISO test standard Road.
Bike trailer approved.
Seat tube-mounted child seat approved.
Derailleur hanger BT-DH-008.
Frame small parts BT-CR-007.
Front thru-axle (ref.) BT-TA-F-601.
Rear thru-axle (ref.) BT-TA-R-602.

Technical specifications – frame & fork

Component Details
Model Hook Frameset.
Suggested colour Metallic Red.
Frame Columbus Cromor double-butted steel, TA dropouts, rack/fender mounts, T47 86.5 mm bottom bracket shell.
Fork full carbon, TA, tapered 1.5"–1 1/8", triple cage mounts (also usable as fender mounts), internal routing for hub dynamo cable.
Headset sealed external headset, 1.5"–1 1/8".
Thru-axles 12 × 100 mm (front) / 12 × 142 mm (rear).
Seatpost clamp Bombtrack Prime 29.8 mm.
Frameset weight 2420 g frame (size M, including TA and hanger) / 600 g fork (300 mm steerer, including TA).
Maximum rider + luggage weight 120 kg.
ASTM use condition 2.
Note The final product may vary in appearance, finish and some minor details.

Geometry & size guide

Size XS S M L XL
Wheel size 650B 650B 700C 700C 700C
Seat tube 460 490 525 545 565
Horizontal top tube 509 523 541 563 580
Seat angle 73.6° 73.6° 73.6° 73.1° 73.1°
Head angle 70.6° 71.1° 71.6° 71.6° 71.6°
Head tube 100 110 130 150 170
BB drop 54 54 64 64 64
Chainstay 410 410 425 425 425
Fork offset 50 50 50 50 50
Trail 65 62 65 65 65
Wheelbase 979 989 1014 1031 1049
Standover 732 752 803 821 841
Reach 355 366 375 386 397
Stack 522 534 565 584 603
Front center 576 586 597 615 632
Axle to crown 400 400 400 400 400
Minimum rider height 150 cm 160 cm 170 cm 179 cm 188 cm
Maximum rider height 161 cm 171 cm 181 cm 190 cm 199 cm

These height recommendations are only a general guide based on rider stature. We can help you interpret the Hook’s geometry and technical standards to choose a build and size that match the project you have in mind: info@bikejamming.it

Configuration & support

We can help you choose compatible components and define the build that best suits your Hook Frameset project.

Frequently asked questions about the Bombtrack Hook Frameset

Is the Bombtrack Hook Frameset a gravel frame or an all-road frame?

The Bombtrack Hook Frameset is designed as a fast gravel platform with a strong all-road character. It is intended for compact gravel, white roads and rough tarmac, with a sportier and more responsive ride than a frame focused more heavily on pure commuting use.

What is the difference between the Bombtrack Hook Frameset and the Arise Frameset?

The Hook is more clearly aimed at fast gravel riding and sporty handling, thanks to its full-carbon fork, T47 bottom bracket and more explicitly performance-oriented platform. The Arise, by contrast, is more versatile and utilitarian, also well suited to commuting and light touring builds.

What tyres can the Bombtrack Hook Frameset take?

The fork accepts up to 650B × 52C or 700C × 45C without fenders. The frame itself is rated for XS–S with 650B × 42C and M–XL with 700C × 42C without fenders.

Is the Bombtrack Hook Frameset compatible with both 700C and 650B?

Yes, but it needs to be understood correctly. The fork has broader compatibility, up to 650B × 52C or 700C × 45C. The frame, however, is size-specific: XS–S are intended for 650B × 42C, while M–XL are intended for 700C × 42C. So this does not mean identical dual-wheel compatibility across all sizes.

Can you fit fenders and racks to the Bombtrack Hook Frameset?

Yes. The frame has mounts for fenders and racks, while the full-carbon fork includes triple cage mounts that can also be used as fender mounts. This allows for sporty commuting or light bikepacking builds.

Is the Bombtrack Hook Frameset compatible with both 1x and 2x drivetrains?

Yes. It supports a 1x chainring up to 40 teeth with a 45 mm chainline, or a 2x setup up to 48 / 32 teeth with a 46.9 mm chainline.

Is the Bombtrack Hook Frameset suitable for light bikepacking?

Yes. The mounts on frame and fork make it suitable for a light bikepacking build, provided the project stays consistent with its nature as a fast gravel frame rather than a heavy touring platform.

What technical standards does the Bombtrack Hook Frameset use?

It uses an 86.5 mm T47 bottom bracket, 12 × 100 mm and 12 × 142 mm thru-axles, flat-mount brakes and a 27.2 mm seatpost. These are modern standards and highly relevant for anyone planning a build from scratch.

  • Brand
  • Reference
    BTHFSMRS
  • Condition
    New

  • Frame
    Gravel / Bikepacking Ready
  • Wheel Size
    27.5/29''
