Ritchey P-29er Frame – Team Edition
The Ritchey P-29er – Team Edition is a steel hardtail frame developed for modern XC and real-world endurance riding, where efficiency, reliability and technical coherence matter more than trends. It is a 29er platform designed around a 100 mm fork, 1x drivetrains and current standards, with no unnecessary compromises.
The construction philosophy is purely Ritchey: proprietary steel tubing, balanced geometry and functional choices aimed at long-term durability and predictable ride behaviour, even over long distances and varying terrain.
Construction highlights
WCS Logic Tubing
The frame is built using Ritchey Logic steel tubing that is triple-butted and heat-treated, developed in-house and optimised specifically for the TIG welding process to Tom Ritchey’s specifications. This results in a frame that prioritises structural strength, longevity and consistent ride quality, while remaining appropriate for XC use.
Integrated Seat Collar
The distinctive fastback seat stay / seat tube junction integrates the seat collar. This solution is both recognisable and functional, securely clamping the seatpost while reducing external parts and potential failure points.
Technical specifications
FRAME
| Item |
Specification |
| Material |
Heat-treated, triple-butted Ritchey Logic steel |
| Construction |
TIG welded |
| Head tube |
Ultra-light forged and machined tapered head tube |
| Treatment |
ED Coat (Electrophoretic Deposition) for corrosion resistance |
| Headset |
Ritchey WCS included (upper IS42/28.6 – lower IS52/40) |
| Upper bearing |
41.8 mm OD / IS42/28.6 (S.H.I.S.) |
| Lower bearing |
51.9 mm OD / IS52/40 (S.H.I.S.) |
| Seat tube clamp |
Integrated (2.5 Nm max for chain guides – 28.6 mm clamp) |
| Seatpost diameter |
27.2 mm with stealth dropper routing |
| Bottom bracket |
BSA 73 mm – English threaded |
| Drivetrain |
1x only |
| Max chainring size |
38T |
| Chainline |
52 mm |
| Direct Mount compatibility |
Not compatible (including T-Type derailleurs and cassettes) |
| Bottle cage mounts |
Two (downtube + seat tube) *size S: downtube only |
| Rear spacing |
BOOST 148 mm |
| Rear axle |
12 mm alloy thru-axle included |
| Cable routing |
External |
| Derailleur hanger |
Replaceable stainless steel |
FORK
| Item |
Specification |
| Recommended fork |
100 mm BOOST suspension fork |
| Rigid alternative |
483 mm axle-to-crown rigid fork |
| Note |
Fork not included |
TIRE COMPATIBILITY
| Item |
Specification |
| Wheel size |
29" |
| Tyre size |
29x2.25 recommended (2.3 max) |
| 27.5" compatibility |
Not compatible |
| Note |
Actual tyre size varies by rim and tyre manufacturer |
BRAKE COMPATIBILITY
| Item |
Specification |
| Standard |
Rear post-mount |
| Rotor size |
160 mm |
| Max rotor |
180 mm with adaptor (sold separately) |
DETAILS
| Item |
Specification |
| Sizes |
S (15") / M (17") / L (19") / XL (20.5") |
| Weight |
2,315 g (size M / 17") |
| Colour |
Team Edition Red, White and Blue Fade & Dirt in Blood |
Size guide (manufacturer reference)
The following sizing is provided by the manufacturer and should be considered a general reference. Final size choice depends on individual proportions and intended use.
-
S: 157–170 cm
-
M: 168–178 cm
-
L: 175–186 cm
-
XL: 183–191 cm
At Bikejamming we offer dedicated size consultation: send us your height and inseam and we will reply within 24 hours.
Spare parts and compatibility support
With frame purchase we provide access to:
-
original Ritchey spare parts
-
compatible Ritchey headsets
-
support for fork, drivetrain and wheel compatibility checks
Why buy from Bikejamming
-
Tracked shipping
-
Bilingual support (Italian / English)
-
Fast, clear responses
-
Real pre-purchase consultation on sizing, setup and compatibility
If you have any technical questions about the Ritchey P-29er Team Edition, we are available to help you build a bike that truly fits your riding style and intended use.
