Gravel - CX

Average votes

GENESIS 2022 CDA 20


New

DISPONIBILE OTTOBRE 2020

PER INFORMAZIONI E PRENOTAZIONI: INFO@BIKEJAMMING.IT

More details

1 049,00 €

Free Shipping in Italy!

Add to wishlist

More info

FEATURES

- ALX8 6066/6061-T6 double-butted aluminium frame.

- Multiple luggage mounting points.

- Mudguard compatible.

- Shimano 9 speed drivetrain.

- Mechanical disc brakes.

- WTB Riddler gravel tyres.



SPECS

Frame ALX8 6066/6061-T6 Double-Butted Aluminium

Fork Genesis Chromoly With Anything Cage Mounts

Headset PT-1606 EC34 Upper / EC34 Lower

Hanger RBSPR40003

COMPONENTS

Handlebars Genesis Alloy, 16 Deg Flare, XS = 400mm, SM/M = 420mm, L-XL = 440mm

Stem Genesis Alloy, 31.8mm, -6 Deg, 100mm

Grips/ Tape Genesis Vexgel

Saddle Genesis Adventure

Seatpost Genesis Alloy 27.2 X 350mm

Pedals NW-91K With Cage

Shifters Shimano Sora ST-R3000 9spd

Rear Derailluer Shimano Sora RD-R3000 9spd

Front Derailluer Shimano Sora FD-R3000

Chainset Shimano FC-R345 50/34t XS/S/M = 170mm, L/XL = 175mm

BB BB-ES300

Chain KMC X9

Cassette Shimano CS-HG400-9 11-34t 9spd

Brakes Promax DSK-717 Road

Brake Levers Shimano Sora ST-R3000 9spd

Rotors Promax DT-160H, 160mm, 6 Bolt

WHEELS & TYRES

Rims Shining DB-31, 32h

Hubs KT-K68, 6 Bolt, 32h

Spokes Steel 14g

Tyres WTB Riddler Comp 700x37c



ADDITONAL INFO

Warranty Lifetime for Frame and Fork

Weight 11.7kg

Frame Weight Limit No Weight Limit

Fork Steerer Size 1 1/8”



Fork Spec:

XS A-C = 401 Offset = 50 Rake/ Trail = 69

SM A-C = 401 Offset = 50 Rake/ Trail = 69

MD A-C = 401 Offset = 50 Rake/ Trail = 66

LG A-C = 401 Offset = 50 Rake/ Trail = 66

XL A-C = 401 Offset = 50 Rake/ Trail = 63



Wheel Size Options N/A

Max Tyre Clearance 700x42C

Hub Size/ Spacing Front 100mm, Rear 135mm

Brake Mount Type Flat Mount 140

Front Mech Size/ Compatibility Band On 31.8mm

Max Chainring Size 50/34, 42t

Seat Tube/Clamp Size 27.2mm/31.8mm

Mech Hanger Type & Part Code Replaceable

Colour Florence & The Green Machine



MOUNTS

Mudguard Mounts Yes

Rack Mounts Yes

Bottle Cage Mounts Yes

Additonal Mounts Anything Cage Mounts



GEOMETRY XS S M L XL

Seat Tube 470 500 530 550 580

Top Tube 524 544 561 582 605

Frame Reach 365 375 385 395 405

Frame Stack 553 572 593 612 633

Head Tube 115 135 155 175 195

Head Angle 71 71 71.5 71.5 72

Seat Angle 74 73.5 73.5 73 72.5

Chainstay 430 430 430 430 430

BB Drop 73 73 73 73 73

Wheelbase 1007 1023 1035 1052 1063

Fork Offset 50 50 50 50 50

Standover 761 784 808 826 850

Stem 100 100 100 100 100

Handlebar 400 420 420 440 440

Crankarm 170 170 170 175 175

Colour Code RAL 120 50 20
